JL-700X Without Protective Cover

Zhaga Book-18 Receptacle

JL-700X Without Protective Cover Features:

Standardized interface defined in Zhaga Book-18
Compact size allowing greater flexibility in luminaire design
Advanced sealing to achieve IP66 with no mounting screws
Scalable solution allows use of Ø40mm photocell and Ø80mm LEX-M in a central management system with the same connection interface
Flexible mounting position, upwards, downwards and sideways facing
Integrated single gasket that seals to both luminaire and module that minimizes assembling time

JL-700X Without Protective Cover Overview:

The JL-700X zhaga book 18 socket, a locking socket, meets the requirements of the Zhaga Book-18 standard interface (Z-LEX-R, Z-LEX-C) and has passed relevant certification, enabling street light controller manufacturers to develop and install equipment for road lighting, regional lighting, or commercial and residential lighting, such as street lights, industrial and mining lights, corridor lights, wall lights, etc.

JL-700X Without Protective Cover Specifications

Model No.	JL-700X
Rated Voltage	24VDC
Power Consumption	1.5A MAX
Related Humidity	96%
Ambient Temperature	-40°C ~ +70 °C
*Wires	AWM 1015, 18/20/22 AWG, 105°C AWM 1007, 18/20/22 AWG, 80°C
IP	IP66
