Name: JL-103 Traditional Button Type
Brand: Shanghai Long-Join Intelligent Technology Inc.
Availability: InStock

JL-103 Overview:

The LongJoin photocell JL-103 photocontrol unit is intended for the automatic regulation of lighting in passageways and at doorways, responding to the existing light levels in the environment. It has received certification from UL LLC and meets the criteria set forth in the UL773A standard, which governs non-industrial photocontrols for lighting control from a reliable street light controller supplier.

JL-103 Traditional Button Type Specifications

Model No.	JL-103A	JL-103B	JL-103C	JL-103D	JL-103EE	JL-103FE
Rated Voltage	120VAC	220~240VAC	208~277VAC	277VAC	347VAC	480VAC
Applicable Voltage Range	—		200~305VAC	—
Rated Frequency	50/60Hz
Wire Length	4"min
Wiring Material	AWG#18, AWM1015	AWG#18, AWM1015	AWG#16, AWM3321	AWG#18, AWM1015	AWG#16, AWM3321	AWG#16 AWM3321
Rated Loading	500W 850VA	500W 850VA	1500W 1500VA	500W 850VA	2000W 2000VA	2000W 2000VA
Power Consumption	1.5W Max.
Operate Levels	10~20Lx Turn-On/30~60Lx Turn-Off
Ambient Temperature	-40℃~+70℃
Related Humidity	96%
Fail Mode	Fail-On
Rainproof Cap	Optional
Certifications						—
